The Smart I/O Configurator GUI contains

Menus

and

Tabs

to configure I/O settings.

File​

  • Open

    – Opens and loads an existing *.

    modus

    file.

  • Close

    – Closes the current file (leaves the application open).

  • Save

    – Saves changes to the file. If the file does not exist, the Save file dialog opens.

  • Open in System Explorer

    – This opens your computer’s file explorer tool to the folder that contains the

    design.modus

    file.

  • Recent Files

    – Lists up to five recently opened *.

    modus

    files, which you can select to re-open.

  • Exit

    – Closes the configurator.

Settings​

  • ModusToolbox™ Settings

    : This opens the Settings tool, an editor that allows you to configure a wide range of settings for your environment, such as proxy settings, content modes, and manifest DB settings. See the Settings tool user guide for more details on specific features.

View​

  • Notice List

    – Shows/hides the Notice List pane, which contains any errors, warnings, tasks, and information notes. See the

    Device Configurator user guide

    for more details.

  • Toolbar

    – Shows/hides the Toolbar.

Help​

  • View Help

    – Opens this document.

  • About

    – Opens the About box for version information, with links to open Infineon.com and the current session log file.
